HYSTER STARTER (LS6935)

Price £135.00 + VAT

Add to Enquiry

Add to Wishlist

Qty:

SUITABLE FOR HYSTER D177 TRUCKS WITH ISUZU C240 TRUCKS

Starter type	Reductor
Type of head	P
Voltage (V)	12
Power KW (kW)	2.2
Neck diameter D1 (mm)	95
Pinion Ø D2 (mm)	32
Number of teeth	9
Direction of rotation of the pinion	CW
Overall length of the starter L (mm)	235
Distance between pinion and flange L2 (mm)	9.5
Distance drive cover (mm)	22
Number of holes	2
Position of fixation	40-10-00
Position of centers	120
Ø mounting holes D3 (mm)	13
Oil sealed yes/no	NO
